PP30A-BAS-AAA
3″ Powder Transfer Pump
Available in 1″, 2″ and 3″ Ports
Transfer and handle your dry process powders faster, cleaner and at a fraction of the cost associated with installed “systems.”
ARO powder pumps offer consistent trouble-free transfer of powders up to 45-lbs. per cubic foot (721 kgs. per cubic meter) dry-weight, such as carbon black, expanded mica, silicones, acrylic resins, 3D printing powders and pharmaceuticals.
Replace Manual Powder Processes:
- Reduce Airborne Contamination – With direct transfer from the powder container to your recipe.
- Unique Patented Air-Induction System – Avoids the possibility of powder pack-out.
- Portable – Can be moved from site to site.
£8,216.00
3″ Powder Transfer Pump
Powder Pump Features
- Replaces Manual Powder Processes
- Reduce Airborne Contamination – With direct transfer from the powder container to your recipe
- Unique Patented Air-Induction System – Avoids the possibility of powder pack-out
- Economical and Simple – Unlike large, complex systems
- Portable – Can be moved from site to site
- Advanced Air-Induction Technology – 4-Way air efficiency valve, delay timer, pump major air valve, air induction valve, main air control valve and air motor muffler
- NPT, BSP and Tri-Clamp material connections
Accessories
- 66312 Air Line Connection Kit: contains Piggyback Filter / Regulator, pipe nipple & 5’ section of hose
- 67183-1 Suction Probe: contains all necessary pump attachment hardware and 10′ of groundable hose to be used with both 2″ and 3″ ported powder pumps
- 637421 Air Section Service Kit
- 637303-XX Fluid Section Service Kit (for PP30A)
- 637309-XX Fluid Section Service Kit (for PP20A)
Pump Casing Materials
- Aluminum
- Stainless Steel
Diaphragm Materials
- Santoprene
- Medical Grade Santoprene
| Weight | 62.4 kg |
|---|---|
| Thread | BSP |
| Size | 3'' |
| Centre | Aluminium |
| Diaphragm | Santoprene |
| Balls | Santoprene |
| Seats | Santoprene |
| Hardware | Stainless Steel |
| Wetted Side | Aluminium |
